Specifications for a Hayward S244T Sand Filter

Jupiterimages/BananaStock/Getty Images

The Hawyard S244T sand filter purifies the water in above ground or in ground swimming pools. The largest of Hawyard's Pro Series line, the S244T incorporates a bed of special sand that functions as the filter media to remove dirt and other impurities from pool water pumped through the filter under pressure. Sand filters for residential pools are a less expensive, lower maintenance alternative to "DE" pool filters which use highly porous, powdered diatomaceous earth as a filter media and are commonly installed on larger public pools. The S244T has a corrosion proof polymer filter tank and full size internal plumbing for free flowing performance. An integral molded drain plug permits draining of tank for winterization without loss of filter sand. Routine backwashing of the filter to cleanse the sand is a simple, single valve operation that may be accomplished in as little as three minutes.

Filter Volume

The S244T has an effective filter area of 3.14 cubic feet. It operates at a maximum working pressure of 50 p.s.i. Pressure readings are relevant in sand type pool filters because they reflect the internal state of the filter media and signal when backwashing is required. Over time, increasing amounts of dirt and debris are trapped by the sand media and pool water flows less freely through the filter. Pressure in the filter slowly increases. Once the filter pressure reading, displayed on a meter on the top of the filter canister, rises 8 p.s.i. to 10 p.s.i. above the reading recorded when the filter was new, the filter must be backwashed to expel the dirt particles. Proper maintenance of a well used private pool at the height of the swimming season will require backwashing a sand filter on at least a weekly basis.

  • The S244T has an effective filter area of 3.14 cubic feet.
  • above the reading recorded when the filter was new, the filter must be backwashed to expel the dirt particles.

Flow Rate

The S244T has a 1.5-inch Vari Flow filter valve. The filter flow rate is 62 gallons per minute. The filter can turn over the entire contents of a 29,760 gallon pool every 8 hours or a 37,200 gallon pool every 10 hours, an acceptable rate for a private, residential swimming pool. Facilities with more intensive use, such as pools at an apartment complex or motel, will benefit from a filter with a higher flow rate and faster turnover time to maintain optimum water quality.

Filter Media

Number 20 industrial silica sand is specified for composition of the filter bed. The total sand capacity is 300 pounds. Unlike beach sand, industrial silica is surface mined from sandstone deposits and is quality controlled for grain size. The Number 20 silica used in the Hayward S244T consists of grains in the range of .45 mm to .55 mm. Sand filters that use Number 20 industrial silica typically filter dirt and debris down to approximately 20 microns in size and the silica media may last as long as ten years before replacement is required. Enhanced filtration can be achieved in sand filters like the S244T by replacing the original equipment industrial silica with zeolite, a natural, microporous mineral approved for use as an alternate media in all sand filters. Zeolite is rated to filter particles down to the 3 micron to 5 micron size. As a filter media, zeolite offers an additional advantage over sand because it filters out chloramines, the chlorine byproducts responsible for the burning eyes sensation swimmers sometimes experience in very active, highly chlorinated pools. Zeolite is about three to four times more expensive than industrial silica.

  • The S244T has a 1.5-inch Vari Flow filter valve.
  • Enhanced filtration can be achieved in sand filters like the S244T by replacing the original equipment industrial silica with zeolite, a natural, microporous mineral approved for use as an alternate media in all sand filters.

Dimensions And Clearance

The S244T filter is 22.5 inches wide and 41 inches high. Its weight when empty is 46 pounds. It requires installation with 18 inches of clearance on the sides and top of the filter.
